WIRE ROPE SLINGS – HARDWARE

When selecting rigging hardware to be connected to wire rope slings, we encourage that the hardware have a diameter greater than the rope diameter so as to achieve D/d ratio in the eye of the sling greater than 1 to 1. We need to make sure that the WLL of the rigging hardware is greater than the sling tension.

WIRE ROPE SLING CAPACITIES – TONS (2000 LBS.) FLEMISH EYE – ASME B30.9 BASED ON 6 X 19, 6 X 36 STEEL IWRC WITH DESIGN FACTOR 5:1

SINGLE LEG WIRE ROPE SLINGS (1-LEG)

HORIZONTAL RATED CAPACITY – 6 -strand wire rope with a steel core (IWRC)

WIRE ROPE

DIAMETER INC.

VERTICAL

TONS

CHOKER

TONS

SHACKLE SIZE

INCH

HOOK SIZE

MM

1/4" 0.65 0.48 5/16" 8
5/16" 1.00 0.74 3/8" 8
3/8" 1.40 1.10 7/16" 8
7/16" 1.90 1.40 1/2" 8
1/2" 2.50 1.90 5/8" 10
9/16" 3.20 2.40 5/8" 13
5/8" 3.90 2.90 3/4" 13
3/4" 5.60 4.10 7/8" 16
7/8" 7.60 5.60 1" 16
1" 9.80 7.20 1-1/4" 19



2-LEG & 4-LEG WIRE ROPE SLINGS

HORIZONTAL RATED CAPACITY – 6 strand wire rope with a steel core (IWRC)

2-LEG 4-LEG

WIRE ROPE

DIAMETER (INCH)

60° 45° 30° 60° 45° 30°
1/4" 1.10 0.91 0.65 2.20 1.80 1.30
5/16" 1.70 1.40 1.00 3.50 2.80 2.00
3/8" 2.50 2.00 1.40 5.00 4.10 2.90
7/16" 3.40 2.70 1.90 6.70 5.50 3.90
1/2" 4.40 3.60 2.50 8.80 7.10 5.10
9/16" 5.50 4.50 3.20 11.0 9.00 6.40
5/8" 6.80 5.50 3.90 14.0 11.0 7.80
3/4" 9.70 7.90 5.60 19.0 16.0 11.0
7/8" 13.0 11.0 7.60 26.0 21.0 15.0
1" 17.0 14.0 9.80 34.0 28.0 20.0

  • All rated Capacities are based on a D/d ratio of >25:1
  • Rated Capacities are based on a D/d ratio of >25:1 and choking angle greater thant 135°.
  • All sling angles refer to the HORIZONTAL angle.
  • All Rated Capacities (WLL's) on multiple leg slings are based on EQUAL loading of all sling legs.
